 Preview VTX1 by Viper RC

View previous topic View next topic Go down
AuthorMessage
Germanese
Admin
avatar

Posts : 844
Join date : 2010-01-13
Age : 34
Location : Cypress, TX

PostSubject: Preview VTX1 by Viper RC   Fri Nov 18, 2011 10:28 am



-True sensored system
-1~2S LiPo Support without radio receiver pack
-Smart Brake System setting by motor RPM and curve profiles
-Dynamic timing boost for competitive track conditions
-High resolution setting (100 steps in most key parameters)
-Battery cut off, ESC temperature, and motor temperature protection
-LED indicator for STOCK/MODIFIED class race
-Auto time-out power off
-ProGauge Multi-Function Meter included
-V-LINK Software for firmware upgrade and PC interface set up (link device sold separately)
-8 Default standard set up profiles that allow quick set up without ProGauge

Similar Pricing as the VTX10
Stay Tuned for Review and more Pics
Back to top Go down
http://formuladrc.com
Germanese
Admin
avatar

Posts : 844
Join date : 2010-01-13
Age : 34
Location : Cypress, TX

PostSubject: Re: Preview VTX1 by Viper RC   Sun Nov 20, 2011 4:04 pm

It is the same size as the VTX10 and it is 3 grams lighter.
VTX1 shares the same aluminum case as VTX10.
It uses different controller board with a different boost controller to support 1S.
It also has it's own firmware (not interchangable with VTX10/10R firmware).
It wil for sure be lighter than VTX10 as it does not have the waterproof glue in it.
Back to top Go down
http://formuladrc.com
Germanese
Admin
avatar

Posts : 844
Join date : 2010-01-13
Age : 34
Location : Cypress, TX

PostSubject: Re: Preview VTX1 by Viper RC   Sat Nov 26, 2011 10:45 am

The VTX1 all aluminum case disperses heat without the use of a fan. It comes preloaded with eight profiles which are all customizable for different applications. Or add your own profile for a track or track condition. The VTX1 is designed for 1/12 and 1/10 scale on road applications without a radio receiver pack. It is also a perfect option for competitive 1/10 off road racing. The top of the line power FETs in the VTX1 will provide ultra-low resistance for blinking mode races. Its sophisticated boost timing firmware will be your best choice for your hunt for podium finishes.

VTX1 Features:

True sensored system

1~2S LiPo Support without radio receiver pack

Smart Brake System setting by motor RPM and curve profiles

Dynamic timing boost for competitive track conditions

High resolutionsetting (100 steps in most key parameters)

Battery cut off, ESC temperature, and motor temperature protection

LED indicator for STOCK/MODIFIED class race

Auto time-out power off

ProGauge Multi-Function Meter included

V-LINK Software for firmware upgrade and PC interface set up (link device sold separately)

8 Default standard set up profiles that allow quick set up without ProGauge

The same size as a credit card, the Progauge is used for tuning the speed control while at the track without the need for a computer. The innovative V-Port on the VTX1 speed control allows for programmability without removing the speed control wire from the receiver. This means less wear over time and you never have to dig for your receiver to make a small adjustment.
Back to top Go down
http://formuladrc.com
Germanese
Admin
avatar

Posts : 844
Join date : 2010-01-13
Age : 34
Location : Cypress, TX

PostSubject: Re: Preview VTX1 by Viper RC   Sat Nov 26, 2011 10:52 am

Motor Type: Sensored Only
Model: VTX1
ON Resistance: 0.00045Ω * 2
Battery Support: 1~2S Li-Po
BEC voltage: 4.5~5.5V
Dimensions (WxLxH): 30x32.5x14.5mm
Back to top Go down
http://formuladrc.com
Germanese
Admin
avatar

Posts : 844
Join date : 2010-01-13
Age : 34
Location : Cypress, TX

PostSubject: Re: Preview VTX1 by Viper RC   Sat Nov 26, 2011 10:52 am

Pre- Order from Dominator.
